Isa
The “ISA”, built in 2015, is a shallow draft anchor handling tug of 23,95 by 8,00 meters with both seagoing and inland certification.
The twin Mitsubishi engines delivering 2.000 BHP which results in 30,6 tons bollard pull. In combination with minimal draft, the 204 BHP bow thruster and twin fixed propellers in nozzles, gives the vessel maximum maneuverability.
The large HEILA marine deck crane with a maximum lift capacity of 5,4 tons(m) at 12,04 meters, the towing winch of 40/60 tons (pull/holding), coupling winches, a movable bridge with view height of 14,50 meters and a clear deck area, makes the vessel more than multifunctional.
She is well equipped to deal with various operations: Inland pushing and towing (certified up to 8.300 ton and max dimensions of 197×23,80m), salvage, ploughing, survey work, dredging & offshore support.
Type | Shallow draft anchor handling tug / utility vessel (2005) |
Flag | NL, Wijk bij Duurstede |
Length x width | 23,95 by 8,00 meters |
Draft (min. – max.) | 3,00 – 3,60 meters |
Gross Tonnage | 130 GT |
Bollard pull | 30,6 ton |
Propulsion | 2x Mitsubishi S6R-Z3MPTAW |
Towing winch | Single drum 40/60 tons pull |
Fuel capacity | 41.000 liters |
